The FAG 6330-M-J20AB-C3 is a current-insulated bearing with a 150mm bore and 320mm outer diameter, designed to handle electrical currents. Its outer ring features a ceramic coating for insulation, preventing electrical damage.
With a dynamic load rating of 300kN and a static load rating of 290kN, it handles heavy loads while spinning smoothly at up to 3600 RPM. The brass cage ensures durability and reduces friction.
The C3 radial clearance allows for thermal expansion, making it suitable for high-speed applications. It’s ideal for electric motors or generators where electrical insulation is needed.
Weighing 25.9kg, it’s robust yet manageable. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial use.
"*" indicates required fields
How Is 6330-M-J20AB-C3 Bearing Engineered for Reliability?
6330-M-J20AB-C3 Bearing features a ceramic-coated outer ring, providing excellent insulation against electrical currents.
The brass cage ensures smooth operation and reduces friction, even at high speeds up to 3600 r/min.
With a basic dynamic load rating of 300.0 kN, it handles heavy loads reliably in demanding applications.
The C3 radial internal clearance allows for thermal expansion, maintaining performance under varying conditions.
Its breakdown voltage of ≤500 V and high electrical resistance make it ideal for electric motor applications.
The 100 µm coating thickness ensures durability, while the damp resistance of 10MΩ guarantees consistent performance.
Industrial Uses of 6330-M-J20AB-C3 Bearing
6330-M-J20AB-C3 Bearing is commonly used in electric motors and generators, where its current-insulating properties prevent damage from stray currents. The ceramic coating on the outer ring ensures reliable performance in high-voltage environments.
What Makes 6330-M-J20AB-C3 Bearing a Preferred Choice?
With a brass cage and C3 clearance, 6330-M-J20AB-C3 Bearing handles heavy loads and high speeds effortlessly. It’s a go-to solution for industries needing durable, low-maintenance bearings.
Built for Heavy-Duty Use: 6330-M-J20AB-C3 Bearing
6330-M-J20AB-C3 Bearing excels in wind turbines and industrial gearboxes, where its dynamic load rating of 300 kN ensures long service life. The damp-resistant insulation adds extra reliability in harsh conditions.
Automotive vs Aerospace: Applications of 6330-M-J20AB-C3 Bearing
In automotive applications, 6330-M-J20AB-C3 Bearing supports high-performance drivetrains, while in aerospace, its precision and insulation are vital for avionics systems. The wide temperature range suits diverse operational needs.
