The FAG 6315-J20AB-C3 is a current-insulated bearing with a 75mm bore and 160mm outer diameter, designed to prevent electrical damage. Its outer ring features a 100µm ceramic coating, offering high electrical resistance up to 50MΩ when dry.
This bearing handles dynamic loads up to 123kN and spins smoothly at speeds up to 6300 RPM. The C3 radial clearance allows for thermal expansion, making it suitable for variable operating conditions.
The sheet metal cage ensures durability, while the insulating coating protects against stray currents. It’s ideal for electric motors or generators where electrical insulation is crucial.
Weighing 3.06kg, it’s robust yet manageable. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial applications.
"*" indicates required fields
Why Choose 6315-J20AB-C3 Bearing for Precision Tasks?
6315-J20AB-C3 Bearing features an outer ring ceramic coating, providing excellent insulation against electrical currents.
Its breakdown voltage of up to 500V ensures reliable performance in electrically demanding environments.
The sheet metal cage maintains precise ball alignment, enhancing smooth operation.
With a dynamic load rating of 123.0 kN, it handles heavy loads efficiently.
6315-J20AB-C3 Bearing operates at speeds up to 6300 r/min, balancing speed and durability.
Its C3 radial clearance allows for thermal expansion, making it suitable for varying temperatures.
The coating offers high electrical resistance, even in damp conditions, ensuring long-term reliability.
This makes 6315-J20AB-C3 Bearing ideal for applications where electrical insulation is critical.
Industrial Uses of 6315-J20AB-C3 Bearing
The 6315-J20AB-C3 Bearing is commonly used in electric motors and generators, where its current-insulating properties prevent damage from stray currents. The ceramic coating on the outer ring ensures reliable performance in high-voltage environments.
In wind turbines, 6315-J20AB-C3 Bearing helps manage electrical currents that can cause wear, extending the lifespan of critical components. Its C3 clearance also accommodates thermal expansion during continuous operation.
For industrial pumps, 6315-J20AB-C3 Bearing’s sheet metal cage provides stability under heavy loads, while the insulating layer protects against electrical erosion. This makes it a dependable choice for harsh operating conditions.
What Makes 6315-J20AB-C3 Bearing a Preferred Choice?
The 6315-J20AB-C3 Bearing is ideal for applications like conveyor systems, where electrical insulation is needed to avoid bearing damage. Its high dynamic load rating ensures it can handle demanding industrial tasks.
In railway systems, 6315-J20AB-C3 Bearing’s resistance to electrical currents makes it suitable for traction motors. The 100 µm ceramic coating provides long-term protection against electrical arcing.
For machine tools, 6315-J20AB-C3 Bearing offers precise performance with its C3 radial clearance, reducing vibration and noise. The damp electrical resistance of 10MΩ further enhances its durability in humid conditions.
Built for Heavy-Duty Use: 6315-J20AB-C3 Bearing
The 6315-J20AB-C3 Bearing is designed for use in compressors, where its insulating properties prevent electrical pitting. The 123 kN dynamic load rating ensures it can withstand rigorous operational demands.
In mining equipment, 6315-J20AB-C3 Bearing’s robust construction handles extreme loads and vibrations. The ceramic coating also resists wear from abrasive particles commonly found in mining environments.
For marine applications, 6315-J20AB-C3 Bearing’s damp resistance of 10MΩ makes it reliable in wet conditions. Its wide temperature range ensures performance in varying climates.
Automotive vs Aerospace: Applications of 6315-J20AB-C3 Bearing
In automotive electric vehicles, 6315-J20AB-C3 Bearing prevents electrical damage in high-voltage systems. Its 75 mm bore diameter fits standard motor designs for seamless integration.
For aerospace systems, 6315-J20AB-C3 Bearing’s lightweight yet durable construction meets stringent performance requirements. The ceramic coating ensures reliability in electrically sensitive applications.
In both sectors, 6315-J20AB-C3 Bearing’s C3 clearance accommodates thermal expansion, making it versatile for dynamic operating conditions. The 37 mm width provides a compact solution for space-constrained designs.
