The FAG 6314-J20C-C3 is a current-insulated bearing with a 70mm bore, 150mm outer diameter, and 35mm width, featuring a ceramic-coated inner ring. It handles dynamic loads up to 104 kN and spins smoothly at speeds up to 6800 RPM.
Its insulating coating prevents electrical damage, with a breakdown voltage of up to 3000V, making it ideal for electric motors or generators. The C3 radial clearance ensures reliable performance under varying temperatures.
The sheet metal cage provides durability, while the coating maintains high electrical resistance even in damp conditions. Compliant with RoHS and REACH standards, it’s a safe choice for industrial applications.
Weighing 2.55kg, this bearing balances strength and insulation for demanding environments where electrical currents are a concern.
"*" indicates required fields
How Is 6314-J20C-C3 Bearing Engineered for Reliability?
6314-J20C-C3 Bearing features an inner ring ceramic coating, providing excellent insulation against electrical currents.
Its breakdown voltage of ≤3000 V ensures safe operation in electrically charged environments.
The sheet metal cage maintains ball alignment, enhancing durability and reducing friction.
With a basic dynamic load rating of 104.0 kN, it handles heavy loads efficiently.
What Makes 6314-J20C-C3 Bearing Suitable for High-Temperature Applications?
6314-J20C-C3 Bearing’s ceramic coating withstands high temperatures, ensuring consistent performance.
The C3 radial internal clearance allows for thermal expansion, preventing premature wear.
Its reference speed of 6800 r/min makes it suitable for high-speed applications.
The bearing’s electrical resistance remains stable even in damp conditions.
Built for Reliability: 6314-J20C-C3 Bearing
6314-J20C-C3 Bearing is designed with a robust sheet metal cage, ensuring long-term stability.
The ceramic-coated inner ring prevents electrical arcing, extending the bearing’s lifespan.
With a basic static load rating of 68.0 kN, it offers reliable support under heavy loads.
Its compact design (70.0 mm x 150.0 mm x 35.0 mm) fits seamlessly into various applications.
Steel vs Ceramic Bearings: Strengths of 6314-J20C-C3 Bearing
6314-J20C-C3 Bearing combines the strength of steel with the insulation properties of ceramic.
The 200 µm ceramic coating ensures high electrical resistance, even in challenging conditions.
Its dynamic load capacity of 104.0 kN makes it a durable choice for industrial use.
The bearing’s compliance with ROHS and REACH standards highlights its environmental safety.
Industrial Uses of 6314-J20C-C3 Bearing
The 6314-J20C-C3 Bearing is commonly used in electric motors and generators, where its ceramic coating prevents electrical arcing. This makes it ideal for industries relying on high-voltage equipment.
In automation systems, 6314-J20C-C3 Bearing ensures smooth operation in robotic arms and conveyor belts. Its C3 clearance allows for thermal expansion, reducing wear over time.
For wind turbines, 6314-J20C-C3 Bearing handles both radial and axial loads efficiently. The insulating coating also protects against stray currents, extending the bearing’s lifespan.
What Makes 6314-J20C-C3 Bearing a Preferred Choice?
The 6314-J20C-C3 Bearing is often chosen for railway applications due to its durability and electrical insulation. Its sheet metal cage provides stability under heavy loads.
In industrial pumps, 6314-J20C-C3 Bearing resists corrosion and electrical damage. The ceramic coating ensures reliable performance even in damp conditions.
Built for Heavy-Duty Use: 6314-J20C-C3 Bearing
The 6314-J20C-C3 Bearing excels in steel mills, where high temperatures and electrical currents are common. Its robust design minimises downtime for maintenance.
For mining equipment, 6314-J20C-C3 Bearing offers reliable performance in harsh environments. The insulating layer prevents damage from electrical discharges.
Medical vs Industrial: Where 6314-J20C-C3 Bearing Excels
In medical imaging devices, 6314-J20C-C3 Bearing provides quiet and precise movement. Its electrical insulation is crucial for sensitive diagnostic equipment.
For industrial compressors, 6314-J20C-C3 Bearing handles high speeds and loads effortlessly. The ceramic coating ensures long-term reliability in demanding conditions.
