The FAG 6314-J20AB-C3 is a current-insulated bearing with a 70mm bore, 150mm outer diameter, and 35mm width, featuring a ceramic-coated outer ring. It handles dynamic loads up to 104 kN and spins smoothly at speeds up to 6800 RPM.
The ceramic coating provides insulation with a breakdown voltage of 500V, making it resistant to electrical currents. Its sheet metal cage ensures durability and stable performance under various conditions.
With a C3 radial clearance, it accommodates thermal expansion in demanding environments. Ideal for electric motors or generators where electrical insulation is crucial.
Weighing 2.55kg, it’s robust yet manageable for installation. Compliant with RoHS and REACH standards for safe and reliable use.
"*" indicates required fields
Performance Features of 6314-J20AB-C3 Bearing
6314-J20AB-C3 Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, protecting the bearing from electrical damage.
With a basic dynamic load rating of 104.0 kN, it handles heavy loads efficiently.
The C3 radial internal clearance ensures reliable performance under varying temperatures.
The sheet metal cage maintains ball alignment, reducing friction and wear.
Its reference speed of 6800 r/min makes it suitable for high-speed applications.
6314-J20AB-C3 Bearing operates in damp conditions, maintaining an electrical resistance of 10MΩ.
The 100 µm layer thickness ensures long-lasting insulation properties.
Industrial Uses of 6314-J20AB-C3 Bearing
The 6314-J20AB-C3 Bearing is commonly used in electric motors and generators, where its ceramic coating prevents electrical arcing. This makes it ideal for industries relying on high-voltage equipment.
In wind turbines, 6314-J20AB-C3 Bearing handles both radial and axial loads while resisting electrical damage. Its C3 clearance ensures reliable performance under varying thermal conditions.
For railway applications, 6314-J20AB-C3 Bearing’s insulation properties protect against stray currents in traction motors. The sheet metal cage adds durability for long-term use in demanding environments.
What Makes 6314-J20AB-C3 Bearing a Preferred Choice?
6314-J20AB-C3 Bearing is often chosen for industrial pumps due to its ability to withstand electrical currents. The ceramic coating ensures consistent operation even in damp conditions.
In conveyor systems, 6314-J20AB-C3 Bearing’s high dynamic load rating supports heavy loads without compromising speed. The C3 clearance accommodates thermal expansion in continuous operation.
Built for Heavy-Duty Use: 6314-J20AB-C3 Bearing
6314-J20AB-C3 Bearing excels in mining equipment, where its insulation prevents damage from electrical discharges. The robust design handles harsh conditions with ease.
For HVAC systems, 6314-J20AB-C3 Bearing’s resistance to damp environments ensures longevity. Its high reference speed suits fans and blowers operating at varying RPMs.
