The FAG 6226-M-J20AA-C3 is a current-insulated bearing with a 130mm bore and 230mm outer diameter, designed to prevent electrical damage. Its outer ring features a ceramic coating for insulation, with a breakdown voltage of up to 3000V.
This bearing handles dynamic loads up to 177kN and operates smoothly at speeds up to 5000 RPM. The brass cage ensures durability, while the C3 radial clearance allows for thermal expansion in demanding conditions.
The coating provides high electrical resistance (50MΩ when dry), making it ideal for electric motors or generators. It’s also compliant with RoHS and REACH standards for safe use.
Weighing 7.3kg, it’s a robust choice for industrial applications where electrical insulation is crucial. The 40mm width offers a compact fit without compromising performance.
"*" indicates required fields
How Is 6226-M-J20AA-C3 Bearing Engineered for Reliability?
6226-M-J20AA-C3 Bearing features an outer ring ceramic coating, providing excellent electrical insulation with a breakdown voltage of up to 3000 V.
Its brass cage ensures smooth operation and reduces friction, even at high speeds of 5000 r/min.
The C3 radial internal clearance allows for thermal expansion, making it suitable for varying operating conditions.
With a basic dynamic load rating of 177.0 kN, it delivers reliable performance in demanding applications.
What Makes 6226-M-J20AA-C3 Bearing Suitable for High-Temperature Applications?
6226-M-J20AA-C3 Bearing’s ceramic coating withstands high temperatures, maintaining insulation properties under thermal stress.
The brass cage material enhances durability, ensuring stable performance in challenging environments.
Its electrical resistance remains effective even in damp conditions, with a minimum of 10MΩ.
The bearing’s robust design and high load capacity make it ideal for industrial applications.
Engineered for Precision: 6226-M-J20AA-C3 Bearing
6226-M-J20AA-C3 Bearing is designed with precise dimensions (130.0 mm x 230.0 mm x 40.0 mm) for accurate fitment.
The ceramic-coated outer ring prevents electrical arcing, protecting machinery from current damage.
Its high dynamic load rating of 177.0 kN ensures long-lasting performance under heavy loads.
The bearing’s C3 clearance accommodates thermal expansion, reducing wear and tear.
Steel vs Ceramic Bearings: Strengths of 6226-M-J20AA-C3 Bearing
6226-M-J20AA-C3 Bearing combines the strength of steel with the insulation benefits of ceramic coating.
The ceramic layer provides up to 3000 V breakdown voltage, preventing electrical damage.
Its brass cage offers superior heat resistance and reduces friction for smoother operation.
With a static load rating of 146.0 kN, it handles heavy loads reliably.
Industrial Uses of 6226-M-J20AA-C3 Bearing
The 6226-M-J20AA-C3 Bearing is commonly used in industrial motors and generators, where its current-insulating properties prevent electrical damage. Its ceramic coating ensures reliable performance in environments with stray currents.
What Makes 6226-M-J20AA-C3 Bearing a Preferred Choice?
With a brass cage and C3 clearance, 6226-M-J20AA-C3 Bearing handles high speeds and loads in wind turbines and large pumps. The coating also resists moisture, making it suitable for damp conditions.
Perfect Fit for Automation: 6226-M-J20AA-C3 Bearing
In automated production lines, 6226-M-J20AA-C3 Bearing reduces downtime by preventing electrical arcing in servo motors. Its 230 mm outer diameter provides stability for heavy rotating parts.
Medical vs Industrial: Where 6226-M-J20AA-C3 Bearing Excels
While 6226-M-J20AA-C3 Bearing isn’t typically used in medical devices, it shines in industrial MRI power units due to its insulation. The 177 kN dynamic load rating ensures longevity in continuous operation.
How Does 6226-M-J20AA-C3 Bearing Improve Performance?
The 6226-M-J20AA-C3 Bearing’s 200 µm ceramic layer blocks up to 3000V, protecting railway traction motors from current leakage. Its 5000 r/min speed rating suits high-RPM applications.
