The FAG 6216-M-J20AB-C3 is a current-insulated bearing with an 80mm bore and 140mm outer diameter, designed to prevent electrical damage. Its outer ring features a ceramic coating, providing insulation up to 500V DC.
With a dynamic load rating of 77kN and a static load rating of 55kN, it handles heavy loads while spinning smoothly at speeds up to 9500 RPM. The brass cage ensures durability and reduces friction.
The C3 radial clearance allows for thermal expansion, making it suitable for high-speed applications. The coating maintains high electrical resistance, even in damp conditions (10MΩ).
Ideal for electric motors or generators where current leakage is a concern, this 1.7kg bearing is RoHS and REACH compliant for safe use in various industries.
"*" indicates required fields
Performance Features of 6216-M-J20AB-C3 Bearing
6216-M-J20AB-C3 Bearing features an outer ring ceramic coating, providing excellent electrical insulation.
This design prevents current passage, reducing the risk of damage in electric motor applications.
The brass cage ensures smooth operation and durability under high-speed conditions.
With a reference speed of 9,500 r/min, it maintains reliable performance in demanding environments.
6216-M-J20AB-C3 Bearing offers a basic dynamic load rating of 77.0 kN, suitable for heavy-duty applications.
Its C3 radial internal clearance allows for thermal expansion, ensuring stability during operation.
The insulating coating has a breakdown voltage of ≤500 V, protecting against electrical damage.
This makes 6216-M-J20AB-C3 Bearing ideal for use in environments with electrical currents.
With a layer thickness of 100 µm, the coating provides long-lasting insulation.
The bearing’s electrical resistance remains high even in damp conditions, ensuring consistent performance.
Industrial Uses of 6216-M-J20AB-C3 Bearing
6216-M-J20AB-C3 Bearing is commonly used in electric motors and generators, where its current-insulating properties prevent electrical damage. The ceramic coating on the outer ring ensures reliable performance in high-voltage environments.
In wind turbine applications, 6216-M-J20AB-C3 Bearing handles both radial and axial loads while resisting electrical arcing. Its brass cage adds durability, making it suitable for long-term use in harsh conditions.
For railway systems, 6216-M-J20AB-C3 Bearing’s C3 clearance accommodates thermal expansion, ensuring smooth operation in traction motors. The high breakdown voltage also protects against stray currents, extending component life.
How Does 6216-M-J20AB-C3 Bearing Improve Performance?
6216-M-J20AB-C3 Bearing enhances efficiency in industrial pumps by reducing energy loss from electrical currents. Its 100 µm ceramic layer provides consistent insulation even in damp conditions.
In CNC machinery, 6216-M-J20AB-C3 Bearing’s high dynamic load rating supports precision movements. The 9500 r/min reference speed allows for smooth high-speed operations without compromising accuracy.
For conveyor systems in mining, 6216-M-J20AB-C3 Bearing’s robust design withstands heavy loads and vibrations. The C3 clearance ensures reliable performance despite temperature fluctuations.
Built for Heavy-Duty Use: 6216-M-J20AB-C3 Bearing
6216-M-J20AB-C3 Bearing is ideal for steel mill equipment, where its insulation prevents current-induced wear. The 77 kN dynamic load rating handles intense operational demands effortlessly.
In marine applications, 6216-M-J20AB-C3 Bearing resists corrosion while maintaining electrical isolation. Its brass cage and ceramic coating work together to ensure longevity in salty environments.
For food processing machinery, 6216-M-J20AB-C3 Bearing’s compliant materials meet hygiene standards. The easy-to-clean design simplifies maintenance in washdown areas.
Automotive vs Aerospace: Applications of 6216-M-J20AB-C3 Bearing
In electric vehicles, 6216-M-J20AB-C3 Bearing prevents motor damage from stray currents. Its compact size fits seamlessly into modern EV drivetrains.
For aircraft systems, 6216-M-J20AB-C3 Bearing’s lightweight design reduces overall weight while ensuring electrical safety. The high-speed capability meets aviation performance requirements.
In hybrid vehicle transmissions, 6216-M-J20AB-C3 Bearing handles switching between power sources smoothly. The insulation properties protect sensitive electronics from voltage spikes.
