The FAG 6030-J20C-C3 is a current-insulated bearing with a 150mm bore and 225mm outer diameter, designed to prevent electrical damage. Its inner ring features a ceramic coating, providing insulation up to 3000V.
With a dynamic load rating of 131kN and a static load rating of 124kN, it handles heavy loads while spinning smoothly at speeds up to 3950 RPM. The C3 radial clearance ensures reliable performance under varying temperatures.
The sheet metal cage adds durability, and the coating maintains high electrical resistance (50MΩ dry, 10MΩ damp). Ideal for electric motors or generators where stray currents are a concern.
Weighing 4.32kg, it’s robust yet manageable. Compliant with RoHS and REACH standards for safe use in industrial applications.
"*" indicates required fields
What Makes 6030-J20C-C3 Bearing Suitable for High-Temperature Applications?
6030-J20C-C3 Bearing features an inner ring ceramic coating, providing excellent insulation against electrical currents.
This design ensures reliable operation in high-temperature environments, with a reference speed of 3,950 r/min.
The sheet metal cage maintains ball alignment, enhancing durability under heavy loads.
With a basic dynamic load rating of 131 kN, it delivers consistent performance in demanding conditions.
6030-J20C-C3 Bearing’s electrical resistance remains stable, even in damp environments.
Its C3 radial internal clearance allows for thermal expansion, ensuring smooth operation.
Industrial Uses of 6030-J20C-C3 Bearing
The 6030-J20C-C3 Bearing is commonly used in electric motors and generators, where its current-insulating properties prevent damage from stray currents. Its ceramic-coated inner ring ensures reliable performance in high-voltage environments.
In wind turbine applications, 6030-J20C-C3 Bearing handles both radial loads and electrical isolation, making it ideal for renewable energy systems. The C3 clearance allows for thermal expansion during continuous operation.
For industrial pumps, 6030-J20C-C3 Bearing’s sheet metal cage provides durability in wet conditions. Its breakdown voltage rating up to 3000V makes it suitable for harsh electrical environments.
What Makes 6030-J20C-C3 Bearing a Preferred Choice?
6030-J20C-C3 Bearing excels in railway traction motors due to its ability to withstand electrical currents and vibrations. The 35mm width offers a compact solution without compromising load capacity.
In conveyor systems, 6030-J20C-C3 Bearing’s damp electrical resistance of 10MΩ ensures consistent performance even in humid conditions. Its 225mm outer diameter provides stable support for heavy loads.
The bearing’s 150mm bore diameter fits standard industrial shafts, while the ceramic coating extends service life in electrically challenging applications.
Built for Heavy-Duty Use: 6030-J20C-C3 Bearing
6030-J20C-C3 Bearing is frequently specified for mining equipment, where its 131kN dynamic load rating handles extreme forces. The current insulation protects against damage from variable frequency drives.
In steel mill machinery, 6030-J20C-C3 Bearing’s 200µm coating thickness provides long-term insulation stability. Its 3950 r/min reference speed suits high-RPM applications.
The bearing’s 4.32kg weight balances strength and portability, making it practical for maintenance in confined industrial spaces. ROHS compliance ensures environmental safety.
