This electrically insulated cylindrical roller bearing has a 120mm bore and 260mm outer diameter, with a width of 55mm. It handles dynamic loads up to 610 kN and operates smoothly at speeds reaching 2800 RPM.
The special coating on its outer ring provides electrical insulation, preventing damage from stray currents. This feature makes it suitable for electric motors or generators where electrical protection is needed.
With a breakdown voltage rating between 1000 and 3000 VDC, it offers reliable performance in electrically challenging environments. The machined brass cage ensures durability and consistent operation.
Weighing 14.6kg, this bearing is robust yet manageable for industrial applications. It complies with RoHS and REACH standards, making it a safe choice for various machinery setups.
"*" indicates required fields
How Does NU 324 ECM/C3VL0241 Bearing Prevent Electrical Damage?
NU 324 ECM/C3VL0241 Bearing features an insulating coating on its outer ring, protecting against electrical currents that cause damage.
This coating provides a breakdown voltage from 1000 to 3000 VDC, ensuring reliable operation in electrically hazardous environments.
The machined brass cage maintains roller alignment, contributing to stable performance under heavy loads.
With a basic dynamic load rating of 610 kN, it handles significant radial forces while offering electrical safety.
Where Is NU 324 ECM/C3VL0241 Bearing Used?
You’ll often spot NU 324 ECM/C3VL0241 Bearing in industrial motors and generators, where its electrical insulation prevents current damage from stray currents. The cylindrical roller design handles heavy radial loads in equipment like large pumps and compressors.
In automotive electric drives, NU 324 ECM/C3VL0241 Bearing supports high-speed operations in hybrid vehicle systems and traction motors. Its C3 clearance accommodates thermal expansion during continuous operation.
For wind turbine applications, NU 324 ECM/C3VL0241 Bearing’s brass cage and insulation coating ensure reliable performance in generator systems. The breakdown voltage rating makes it suitable for power generation equipment.
