The NU 210 ECM/C3VL0241 is an electrically insulated cylindrical roller bearing, measuring 75mm by 160mm by 37mm. Its outer ring features a special coating to prevent electrical currents from damaging the bearing.
With a dynamic load rating of 280kN and a static load rating of 265kN, it handles heavy loads efficiently. The bearing can reach speeds up to 5300 RPM, making it suitable for high-performance applications.
The machined brass cage ensures durability, while the C3 radial clearance allows for thermal expansion. The insulation coating provides a breakdown voltage of 1000-3000 VDC and a minimum resistance of 50MΩ.
Ideal for electric motors or generators, this bearing prevents electrical arcing. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial use. Weighing 0.48kg, it balances strength and practicality.
"*" indicates required fields
How Is NU 210 ECM/C3VL0241 Bearing Engineered for Reliability?
NU 210 ECM/C3VL0241 Bearing features an insulation coating on the outer ring, preventing electrical damage in high-voltage environments.
The machined brass cage ensures smooth operation and reduces friction, even at high speeds up to 5,300 rpm.
With a basic dynamic load rating of 280 kN, it handles heavy radial loads reliably.
Its breakdown voltage ranges from 1,000 to 3,000 VDC, making it suitable for electric motor applications.
Industrial Uses of NU 210 ECM/C3VL0241 Bearing
NU 210 ECM/C3VL0241 Bearing is commonly used in electric motors and generators, where its electrically insulated coating prevents current leakage. The brass cage ensures smooth operation even under high rotational speeds.
Where Is NU 210 ECM/C3VL0241 Bearing Used?
In wind turbines, NU 210 ECM/C3VL0241 Bearing handles radial loads while its insulation protects against electrical arcing. The C3 clearance makes it suitable for applications with thermal expansion.
Built for Heavy-Duty Use: NU 210 ECM/C3VL0241 Bearing
NU 210 ECM/C3VL0241 Bearing excels in industrial gearboxes, where its high dynamic load rating ensures long service life. The VL0241 coating provides reliable insulation in harsh environments.
Automotive vs Aerospace: Applications of NU 210 ECM/C3VL0241 Bearing
In automotive alternators, NU 210 ECM/C3VL0241 Bearing reduces electrical interference, while in aerospace, its lightweight design and insulation are valued. The machined brass cage adds durability.
Perfect Fit for Automation: NU 210 ECM/C3VL0241 Bearing
NU 210 ECM/C3VL0241 Bearing is ideal for robotic arms, where its precision and insulation prevent electrical damage. The high reference speed supports efficient automation processes.
