The 6326M/C4VL0241 is an electrically insulated ball bearing with a 130mm bore and 280mm outer diameter, designed to handle high loads and speeds. Its outer ring features a special coating to prevent electrical currents from passing through.
With a dynamic load rating of 229kN and a static load rating of 216kN, it can support heavy-duty applications while spinning smoothly at up to 5000 RPM. The brass cage adds durability and stability during operation.
The insulation coating provides a breakdown voltage of 1000-3000V and electrical resistance of 50-200MΩ, making it ideal for electric motors or generators. Its C4 radial clearance ensures reliable performance under varying temperatures.
Weighing 17.3kg, this robust bearing is RoHS and REACH compliant, suitable for industrial machinery where electrical insulation is crucial. The 100-500µm coating thickness offers long-lasting protection against electrical damage.
"*" indicates required fields
Why Choose 6326M/C4VL0241 Bearing for Precision Tasks?
6326M/C4VL0241 Bearing features an insulating coating on the outer ring, preventing electrical currents from damaging the bearing.
This makes it ideal for applications where electrical insulation is crucial.
The brass cage ensures smooth operation and reduces friction, enhancing the bearing’s performance.
With a basic dynamic load rating of 229.0 kN, it handles heavy loads efficiently.
6326M/C4VL0241 Bearing operates at speeds up to 5000 r/min, offering reliability in high-speed applications.
Its breakdown voltage ranges from 1000 to 3000 V, providing robust electrical protection.
The C4 radial internal clearance allows for thermal expansion, ensuring consistent performance.
This bearing is compliant with ROHS and REACH, meeting environmental and safety standards.
Industrial Uses of 6326M/C4VL0241 Bearing
6326M/C4VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing and extends component life. The brass cage adds durability, making it suitable for high-speed industrial applications.
In wind turbines, 6326M/C4VL0241 Bearing handles heavy loads while its insulation protects against stray currents. The C4 clearance ensures smooth operation even under varying thermal conditions.
For railway traction systems, 6326M/C4VL0241 Bearing’s high breakdown voltage makes it reliable in electrified environments. Its robust design also withstands the vibrations and shocks common in rail transport.
What Makes 6326M/C4VL0241 Bearing a Preferred Choice?
6326M/C4VL0241 Bearing is ideal for CNC machinery, where precision and electrical insulation are critical. The coating thickness can be tailored to specific voltage requirements, offering flexibility.
In medical imaging devices, 6326M/C4VL0241 Bearing’s low electrical resistance ensures accurate performance. Its compliance with ROHS and REACH standards also makes it safe for sensitive environments.
Built for Heavy-Duty Use: 6326M/C4VL0241 Bearing
6326M/C4VL0241 Bearing excels in steel mills, where high temperatures and electrical interference are common. The static load rating of 216 kN ensures longevity under extreme conditions.
For printing presses, 6326M/C4VL0241 Bearing’s insulation prevents damage from static electricity. The reference speed of 5000 r/min keeps operations running smoothly without downtime.
