The 6326/C3VL0241 is an electrically insulated ball bearing with a 130mm bore and 280mm outer diameter, designed to prevent electrical currents from passing through. Its outer ring features a special coating that resists voltages up to 3000V, making it safe for use in electric motors or generators.
With a dynamic load rating of 229kN and a static load rating of 216kN, it handles heavy loads while maintaining smooth rotation at speeds up to 5000 RPM. The C3 radial clearance allows for slight expansion under heat, ensuring reliable performance.
The sheet metal cage provides durability, and the insulation layer (100-500µm thick) offers electrical resistance of 50-200 MΩ. This makes it ideal for applications where electrical arcing could damage standard bearings.
Weighing 14.7kg, it’s a robust choice for industrial machinery. Compliant with RoHS and REACH standards, it’s both safe and environmentally friendly. Perfect for wind turbines or electric vehicles where electrical insulation is crucial.
"*" indicates required fields
How Is 6326/C3VL0241 Bearing Engineered for Reliability?
6326/C3VL0241 Bearing features an insulation coating on the outer ring, preventing electrical currents from damaging the bearing.
This design ensures reliable operation in environments with electrical interference.
With a basic dynamic load rating of 229.0 kN, 6326/C3VL0241 Bearing handles heavy loads efficiently.
Its reference speed of 5000.0 r/min makes it suitable for high-speed applications.
The sheet metal cage maintains ball alignment, reducing friction and wear.
6326/C3VL0241 Bearing’s C3 radial internal clearance allows for thermal expansion under heavy loads.
Breakdown voltage ranges from 1000 to 3000 V, ensuring protection against electrical damage.
This makes 6326/C3VL0241 Bearing ideal for use in electric motors and generators.
Common Applications of 6326/C3VL0241 Bearing
6326/C3VL0241 Bearing is widely used in electric motors and generators, where its insulating coating prevents electrical arcing and extends component life. The C3 clearance ensures smooth operation even under varying thermal conditions.
In wind turbine systems, 6326/C3VL0241 Bearing handles high dynamic loads while maintaining electrical insulation. Its robust design makes it suitable for harsh outdoor environments with fluctuating temperatures.
For industrial pumps, 6326/C3VL0241 Bearing offers reliable performance with its sheet metal cage and high breakdown voltage. The insulation layer protects against stray currents, reducing downtime for maintenance.
Where Is 6326/C3VL0241 Bearing Used?
6326/C3VL0241 Bearing is a go-to choice for railway traction motors, where electrical insulation is critical for safety. Its high reference speed also supports efficient power transmission.
In manufacturing equipment, 6326/C3VL0241 Bearing ensures stable operation in CNC machines and robotic arms. The insulation coating adds an extra layer of protection against electrical damage.
Built for Heavy-Duty Use: 6326/C3VL0241 Bearing
6326/C3VL0241 Bearing excels in mining machinery, handling heavy loads while resisting electrical wear. The thick insulation layer provides durability in dusty and humid conditions.
For food processing equipment, 6326/C3VL0241 Bearing’s compliant materials meet hygiene standards. Its electrical resistance prevents contamination from static discharge.
Automotive vs Aerospace: Applications of 6326/C3VL0241 Bearing
In electric vehicles, 6326/C3VL0241 Bearing supports battery cooling systems with its insulation properties. The high static load rating ensures longevity in frequent start-stop cycles.
For aircraft auxiliary systems, 6326/C3VL0241 Bearing’s lightweight design and electrical safety features are ideal. It meets stringent aviation standards for reliability and performance.
