The 6324M/C3VL0241 is an electrically insulated ball bearing with a 120mm bore and 260mm outer diameter, designed to handle both dynamic and static loads efficiently. Its outer ring features a special insulation coating to prevent electrical currents from damaging the bearing.
With a dynamic load rating of 216kN and a static load rating of 186kN, it performs reliably under heavy loads. The bearing can reach speeds up to 5600 RPM, making it suitable for high-speed applications.
The brass cage ensures smooth operation, while the C3 radial clearance allows for thermal expansion. The insulation coating offers a breakdown voltage of 1000-3000V and electrical resistance of 50-200 MΩ.
Ideal for use in electric motors or generators, this bearing helps prevent electrical arcing. Compliant with RoHS and REACH standards, it’s a safe and durable choice for industrial applications. Weighing 14.1kg, it’s robust yet manageable for its size.
"*" indicates required fields
How Is 6324M/C3VL0241 Bearing Engineered for Reliability?
6324M/C3VL0241 Bearing features an insulation coating on the outer ring, preventing electrical currents from damaging the bearing.
This design ensures reliable operation in electrically charged environments, with a breakdown voltage ranging from 1000 to 3000 V.
The brass cage in 6324M/C3VL0241 Bearing enhances durability and maintains ball alignment under high loads.
With a basic dynamic load rating of 216.0 kN, it handles demanding applications with ease.
6324M/C3VL0241 Bearing operates smoothly at speeds up to 5600 r/min, balancing performance and longevity.
Its C3 radial internal clearance allows for thermal expansion, ensuring consistent operation in varying conditions.
Industrial Uses of 6324M/C3VL0241 Bearing
6324M/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing and extends component life. The brass cage adds durability, making it suitable for high-speed industrial applications.
Where Is 6324M/C3VL0241 Bearing Used?
In wind turbines, 6324M/C3VL0241 Bearing handles high dynamic loads while its insulation protects against stray currents. The C3 clearance ensures reliable performance even under thermal expansion.
Perfect Fit for Automation: 6324M/C3VL0241 Bearing
This bearing works well in robotic arms and CNC machines, where electrical insulation reduces downtime. Its balanced design supports smooth rotation at speeds up to 5600 r/min.
Automotive vs Aerospace: Applications of 6324M/C3VL0241 Bearing
In hybrid vehicles, 6324M/C3VL0241 Bearing manages electrical isolation in drivetrains, while in aerospace, its lightweight construction aids in auxiliary systems. The coating resists wear in both environments.
