The 6317M/C3VL0241 is an electrically insulated ball bearing with an 85mm bore and 180mm outer diameter, designed to prevent electrical currents from passing through. Its outer ring features a special coating that resists voltages up to 3000V, making it safe for electric motor applications.
This bearing handles dynamic loads up to 140kN and spins smoothly at speeds up to 8000 RPM. The brass cage ensures durability, while the C3 radial clearance allows for thermal expansion in high-speed operations.
With an insulation layer thickness of 100-500µm and electrical resistance of 50-200 MΩ, it effectively reduces electrical damage. Ideal for use in generators, wind turbines, or any equipment where electrical insulation is crucial.
Weighing 4.93kg, it’s robust yet manageable for industrial use. Compliant with RoHS and REACH standards, it’s a reliable choice for both replacements and new installations.
"*" indicates required fields
How Is 6317M/C3VL0241 Bearing Engineered for Reliability?
6317M/C3VL0241 Bearing features an insulation coating on the outer ring, preventing electrical current damage.
Its breakdown voltage ranges from 1000 to 3000 V, making it suitable for electric motor applications.
The brass cage ensures smooth operation, even at high speeds up to 8000 r/min.
With a basic dynamic load rating of 140.0 kN, it handles heavy loads reliably.
Designed for longevity, 6317M/C3VL0241 Bearing has a layer thickness of 100~500 µm for consistent insulation.
Its electrical resistance of 50~200 MΩ further enhances performance in electrically demanding environments.
Industrial Uses of 6317M/C3VL0241 Bearing
The 6317M/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulating coating prevents electrical arcing and prolongs component life. Its brass cage ensures smooth operation even under high rotational speeds.
Where Is 6317M/C3VL0241 Bearing Used?
You’ll often find 6317M/C3VL0241 Bearing in wind turbines and industrial pumps, thanks to its ability to handle both dynamic and static loads efficiently. The C3 radial clearance makes it suitable for applications with thermal expansion concerns.
Built for Heavy-Duty Use: 6317M/C3VL0241 Bearing
This bearing excels in conveyor systems and heavy machinery, where its high breakdown voltage and robust construction are essential. The 180mm outer diameter provides excellent stability under load.
Medical vs Industrial: Where 6317M/C3VL0241 Bearing Excels
While 6317M/C3VL0241 Bearing isn’t typically used in medical devices, it’s perfect for industrial equipment like CNC machines. Its insulation properties make it ideal for environments with electrical interference.
Practical Applications of 6317M/C3VL0241 Bearing
In automation systems, 6317M/C3VL0241 Bearing supports robotic arms and precision tools, ensuring reliable performance. The 85mm bore diameter allows for easy integration with various shaft sizes.
