The 6315-Z/C3VL0241 is an electrically insulated ball bearing with a 75mm bore and 160mm outer diameter, designed to prevent electrical currents from passing through. Its outer ring features a special coating that provides insulation, making it ideal for electric motors and generators.
This bearing can handle dynamic loads up to 119kN and operates smoothly at speeds up to 9000 RPM. The C3 radial internal clearance ensures reliable performance under varying temperatures and loads.
The insulation coating offers a breakdown voltage of 1000-3000V and electrical resistance of 50-200 MΩ, protecting against electrical damage. Its sheet metal cage adds durability while keeping the weight manageable at 3.03kg.
Perfect for applications where electrical insulation is crucial, such as wind turbines or industrial drives. Compliant with RoHS and REACH standards, it’s a safe and reliable choice for demanding environments.
"*" indicates required fields
How Is 6315-Z/C3VL0241 Bearing Engineered for Reliability?
6315-Z/C3VL0241 Bearing features an insulation coating on the outer ring, preventing electrical current damage.
Its breakdown voltage ranges from 1000 to 3000 V, making it suitable for electric motor applications.
The sheet metal cage ensures smooth operation, even at high speeds up to 9000 r/min.
With a basic dynamic load rating of 119 kN, it handles heavy loads reliably.
6315-Z/C3VL0241 Bearing’s C3 radial internal clearance allows for thermal expansion in demanding conditions.
The coating thickness of 100-500 µm provides consistent electrical resistance of 50-200 MΩ.
Industrial Uses of 6315-Z/C3VL0241 Bearing
6315-Z/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulation coating prevents electrical arcing and extends component life. The C3 radial clearance ensures smooth operation even under varying thermal conditions.
What Makes 6315-Z/C3VL0241 Bearing a Preferred Choice?
In wind turbines, 6315-Z/C3VL0241 Bearing handles high dynamic loads while its insulating properties protect against stray currents. The sheet metal cage offers durability in these demanding environments.
Perfect Fit for Automation: 6315-Z/C3VL0241 Bearing
6315-Z/C3VL0241 Bearing works well in robotic systems, where electrical insulation prevents damage from induced currents. Its high reference speed suits precision applications like CNC machinery.
Medical vs Industrial: Where 6315-Z/C3VL0241 Bearing Excels
While not typically used in medical devices, 6315-Z/C3VL0241 Bearing shines in industrial settings like conveyor systems. The insulation coating proves invaluable in facilities with variable power quality.
Essential Roles of 6315-Z/C3VL0241 Bearing
6315-Z/C3VL0241 Bearing supports high-speed operations in pumps and compressors, withstanding both radial and axial loads. The breakdown voltage range makes it adaptable to different electrical environments.
