The 6312/C3VL0241 is an electrically insulated ball bearing with a 60mm bore and 130mm outer diameter, designed to prevent electrical currents from passing through. It handles dynamic loads up to 85.2 kN and spins smoothly at speeds up to 11000 RPM.
Its outer ring features a special coating with a breakdown voltage of 1000-3000V, making it ideal for electric motors or generators. The sheet metal cage ensures durability, while the C3 radial clearance allows for thermal expansion.
Weighing 1.65kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for industrial applications. Perfect for environments where electrical insulation is crucial to prevent bearing damage.
"*" indicates required fields
Why Choose 6312/C3VL0241 Bearing for Precision Tasks?
6312/C3VL0241 Bearing features an insulating coating on the outer ring, preventing electrical current passage.
This design ensures reliable performance in electrically sensitive environments, reducing the risk of damage.
With a breakdown voltage ranging from 1000 to 3000 V, it offers excellent protection against electrical discharge.
The sheet metal cage maintains ball alignment, enhancing smooth operation and longevity.
Its basic dynamic load rating of 85.2 kN makes it suitable for heavy-duty applications.
The C3 radial internal clearance allows for thermal expansion, ensuring consistent performance.
The reference speed of 11000 r/min balances efficiency and durability.
6312/C3VL0241 Bearing is compliant with ROHS and REACH, meeting environmental standards.
Industrial Uses of 6312/C3VL0241 Bearing
6312/C3VL0241 Bearing is commonly used in electric motors and generators, where its insulation coating prevents electrical arcing and extends component life. The C3 radial clearance also accommodates thermal expansion in high-speed applications.
What Makes 6312/C3VL0241 Bearing a Preferred Choice?
With its breakdown voltage of 1000-3000V, 6312/C3VL0241 Bearing reliably protects sensitive equipment like wind turbine generators from stray currents. The sheet metal cage ensures smooth rotation even under heavy loads.
Perfect Fit for Automation: 6312/C3VL0241 Bearing
In robotic assembly lines, 6312/C3VL0241 Bearing’s electrical insulation prevents damage from induced currents while maintaining precision movement. Its 130mm outer diameter provides stable support for rotating arms.
Medical vs Industrial: Where 6312/C3VL0241 Bearing Excels
While suitable for industrial pumps, 6312/C3VL0241 Bearing’s clean operation also makes it ideal for medical imaging devices where electrical interference must be minimised. The ROHS compliance ensures safe use in sensitive environments.
How Does 6312/C3VL0241 Bearing Support High-Speed Operations?
The bearing’s 11000 r/min reference speed and C3 clearance make it perfect for spindle applications in CNC machinery. Insulation coating maintains performance even when electrical currents are present nearby.
