The 6217M/C3VL0241 is an electrically insulated ball bearing with an 85mm bore and 150mm outer diameter, designed to prevent electrical currents from damaging machinery. Its outer ring features a special coating that provides insulation, with a breakdown voltage of up to 3000V.
With a dynamic load rating of 87.1 kN and a static load rating of 64.0 kN, it handles heavy loads while maintaining smooth operation. The brass cage ensures durability, and the C3 radial clearance allows for thermal expansion in demanding conditions.
This bearing can reach speeds of up to 9000 RPM, making it suitable for high-speed applications like electric motors or generators. The insulation coating also offers electrical resistance of 50-200 MΩ, protecting against stray currents.
Weighing 2.14kg, it’s a robust choice for industrial use. Compliant with RoHS and REACH standards, it’s both safe and reliable for long-term performance. Ideal for environments where electrical insulation is crucial.
"*" indicates required fields
How Is 6217M/C3VL0241 Bearing Engineered for Reliability?
6217M/C3VL0241 Bearing features an insulating coating on the outer ring, preventing electrical currents from damaging the bearing.
This design ensures reliable operation in electrically charged environments, reducing downtime.
The brass cage enhances stability, while the C3 radial internal clearance accommodates thermal expansion.
With a breakdown voltage of 1000~3000 V, it offers consistent performance in demanding conditions.
What Makes 6217M/C3VL0241 Bearing Suitable for High-Temperature Applications?
6217M/C3VL0241 Bearing’s insulation coating withstands high temperatures, maintaining performance in harsh environments.
The brass cage and chrome steel construction provide durability under heavy loads and thermal stress.
Its C3 clearance allows for expansion, ensuring smooth operation even at elevated temperatures.
With a reference speed of 9000 r/min, it balances speed and reliability.
Designed for Durability: 6217M/C3VL0241 Bearing
6217M/C3VL0241 Bearing’s robust construction includes a brass cage and chrome steel components for long-lasting use.
The insulating coating protects against electrical damage, extending the bearing’s service life.
Its dynamic load rating of 87.1 kN ensures reliable performance under heavy loads.
The C3 radial clearance accommodates thermal expansion, reducing wear over time.
Why Choose 6217M/C3VL0241 Bearing for Precision Tasks?
6217M/C3VL0241 Bearing’s precise design ensures smooth operation in electrically sensitive applications.
The insulating coating prevents current passage, protecting machinery from damage.
With a static load rating of 64.0 kN, it handles demanding tasks with ease.
The brass cage maintains ball alignment, reducing friction and noise.
Industrial Uses of 6217M/C3VL0241 Bearing
This bearing is commonly used in electric motors and generators, where its insulation coating prevents electrical arcing and extends component life. The brass cage adds durability, making it suitable for high-speed industrial applications.
Where Is 6217M/C3VL0241 Bearing Used?
You’ll often find this bearing in wind turbines, where its ability to handle high dynamic loads and resist electrical currents is crucial. The C3 clearance ensures reliable performance even under thermal expansion.
Built for Heavy-Duty Use: 6217M/C3VL0241 Bearing
In conveyor systems and heavy machinery, this bearing’s robust design handles both radial and axial loads effortlessly. The insulation coating also makes it a safe choice for environments with stray currents.
Automotive vs Aerospace: Applications of 6217M/C3VL0241 Bearing
While it’s used in hybrid vehicle drivetrains for its electrical insulation, this bearing also suits aerospace applications where reliability and weight matter. The high reference speed ensures smooth operation in both fields.
Perfect Fit for Automation: 6217M/C3VL0241 Bearing
In robotic arms and automated production lines, this bearing’s precision and insulation reduce downtime. The consistent electrical resistance keeps sensitive electronics safe from damage.
