The 3209 A-2ZTN9/MT33 is a double-row angular contact ball bearing with a 45mm bore and 85mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 11700 lbf and operates smoothly at speeds up to 7500 RPM.
Its shielded design keeps dirt out while the stainless steel cage ensures durability. The bearing is pre-lubricated for easy use and performs well in temperatures from -30°C to 110°C.
This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for machinery requiring high radial load capacity, such as pumps or gear systems.
Weighing 0.63kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for various industrial applications.
"*" indicates required fields
Why Choose 3209 A-2ZTN9/MT33 Bearing for Precision Tasks?
3209 A-2ZTN9/MT33 Bearing features a double-row angular contact design, ideal for handling combined radial and axial loads.
Its chrome steel rings and balls ensure durability and consistent performance under high stress.
The shielded design of 3209 A-2ZTN9/MT33 Bearing protects against contaminants, extending its service life.
With a dynamic radial load capacity of 11700 lbf, it excels in demanding applications.
3209 A-2ZTN9/MT33 Bearing operates smoothly at speeds up to 7,500 rpm, thanks to its precision engineering.
The stainless steel cage maintains ball alignment, reducing friction and wear.
Designed for a temperature range of -30° to 110°C, 3209 A-2ZTN9/MT33 Bearing performs reliably in various conditions.
Its P6 tolerance class ensures high precision and consistent operation.
Common Applications of 3209 A-2ZTN9/MT33 Bearing
In industrial machinery, 3209 A-2ZTN9/MT33 Bearing handles angular contact loads effectively, making it suitable for machine tools and conveyor systems.
Its double-row design provides stability, while the shielded seals protect against contaminants in demanding environments.
Where Is 3209 A-2ZTN9/MT33 Bearing Used?
You’ll often find 3209 A-2ZTN9/MT33 Bearing in automotive gearboxes, where its high radial load capacity ensures smooth power transmission.
The lubricated design also helps maintain performance under continuous use.
Built for Heavy-Duty Use: 3209 A-2ZTN9/MT33 Bearing
This bearing excels in automation equipment like robotic arms, thanks to its precise angular contact and stainless steel cage.
The P6 tolerance class ensures consistent performance in high-precision applications.
Automotive vs Aerospace: Applications of 3209 A-2ZTN9/MT33 Bearing
In automotive systems, 3209 A-2ZTN9/MT33 Bearing supports gearboxes and drivetrains with reliable load handling.
For aerospace applications, its metric sizing and shielded design make it a practical choice for auxiliary equipment.
Essential Roles of 3209 A-2ZTN9/MT33 Bearing
Medical imaging devices benefit from 3209 A-2ZTN9/MT33 Bearing’s smooth operation and resistance to wear.
The chrome steel construction ensures durability in high-use scenarios, while the lubricated design reduces maintenance needs.
