The 3208 A-2RS1 is a double row angular contact ball bearing with a 40mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 10800 lbf and operates smoothly at speeds up to 5600 RPM.
Its sealed design keeps lubrication in and contaminants out, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.
This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like pumps or gearboxes where angular contact and double row support are needed.
Weighing 0.57kg, it balances strength and compactness. Compliant with RoHS and REACH standards for safe and eco-friendly use.
"*" indicates required fields
Performance Features of 3208 A-2RS1 Bearing
3208 A-2RS1 Bearing is built with double-row angular contact design, offering balanced load distribution and stability.
Its chrome steel rings and balls enhance durability, making it suitable for high radial loads.
The sealed design of 3208 A-2RS1 Bearing protects against contaminants, ensuring smooth operation in harsh environments.
With a dynamic radial load capacity of 10,800 lbf, it handles demanding applications with ease.
3208 A-2RS1 Bearing’s stainless steel cage maintains ball alignment, reducing friction and extending service life.
It operates efficiently at speeds up to 5,600 rpm, providing reliable performance.
The P6 tolerance class of 3208 A-2RS1 Bearing ensures precision, making it ideal for applications requiring high accuracy.
Its temperature range of -30° to 110°C allows for versatile use in various conditions.
Industrial Uses of 3208 A-2RS1 Bearing
3208 A-2RS1 Bearing is commonly used in machine tools, where its double-row design handles combined radial and axial loads efficiently. The sealed construction helps keep contaminants out, extending service life in dusty workshop environments.
What Makes 3208 A-2RS1 Bearing a Preferred Choice?
In automotive applications like wheel hubs, 3208 A-2RS1 Bearing offers reliable performance with its chrome steel construction. The P6 tolerance class ensures precise operation, even under varying road conditions.
Perfect Fit for Automation: 3208 A-2RS1 Bearing
For robotic arms in assembly lines, 3208 A-2RS1 Bearing provides smooth movement thanks to its angular contact design. The lubricated seals reduce maintenance needs in continuous operation settings.
Medical vs Industrial: Where 3208 A-2RS1 Bearing Excels
While suitable for industrial gearboxes, 3208 A-2RS1 Bearing also works well in medical centrifuges where consistent rotation matters. Its stainless steel cage prevents corrosion in both environments.
Where to Use 3208 A-2RS1 Bearing
In conveyor systems, 3208 A-2RS1 Bearing handles heavy loads while maintaining alignment. The 80mm outer diameter provides stability for medium-duty material handling applications.
