The 3206 A-2RS1TN9/MT33 is a double-row angular contact ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6862 lbf and operates smoothly at speeds up to 7500 RPM.
Its sealed design keeps lubrication in and contaminants out, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.
This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like pumps or gearboxes where angular contact loads are present.
Weighing 0.29kg, it balances strength and lightness. Compliant with RoHS and REACH standards for safe and eco-friendly use.
"*" indicates required fields
Performance Features of 3206 A-2RS1TN9/MT33 Bearing
3206 A-2RS1TN9/MT33 Bearing is built with chrome steel rings and balls, offering excellent resistance to radial loads.
Its dynamic radial load capacity reaches 6862 lbf, ensuring dependable performance in various applications.
The sealed design protects against contaminants, making it suitable for harsh environments.
With a maximum speed of 7,500 rpm, it delivers both durability and efficiency.
How Does 3206 A-2RS1TN9/MT33 Bearing Reduce Friction?
3206 A-2RS1TN9/MT33 Bearing features a double-row angular contact design, distributing loads evenly to minimise friction.
The stainless steel cage maintains ball alignment, reducing wear and ensuring smooth operation.
Pre-lubricated for immediate use, it requires less maintenance over time.
Its P6 tolerance class guarantees consistent performance in precision applications.
Built for Reliability: 3206 A-2RS1TN9/MT33 Bearing
3206 A-2RS1TN9/MT33 Bearing’s sealed construction keeps out dust and moisture, enhancing its lifespan.
The chrome steel components resist wear, even under heavy radial loads.
It operates smoothly within a temperature range of -30° to 110°C, adapting to various conditions.
With a static radial load capacity of 4950 lbf, it provides reliable support in demanding setups.
Steel vs Ceramic Bearings: Strengths of 3206 A-2RS1TN9/MT33 Bearing
3206 A-2RS1TN9/MT33 Bearing uses high-quality chrome steel for both rings and balls, ensuring strength and durability.
Unlike ceramic options, it offers a cost-effective solution without compromising performance.
The stainless steel cage adds corrosion resistance, making it suitable for diverse environments.
Its sealed design further enhances protection, reducing the need for frequent maintenance.
Common Applications of 3206 A-2RS1TN9/MT33 Bearing
In industrial settings, 3206 A-2RS1TN9/MT33 Bearing is commonly used in machine tools and conveyor systems, where its double-row design handles combined radial and axial loads efficiently. The sealed construction helps keep contaminants out, extending service life in dusty environments.
For automotive applications, 3206 A-2RS1TN9/MT33 Bearing works well in gearboxes and wheel hubs, offering reliable performance under angular contact loads. Its P6 tolerance ensures smooth operation, even at higher speeds.
In robotics, 3206 A-2RS1TN9/MT33 Bearing’s stainless steel cage and chrome steel rings provide durability for precision movements in robotic arms. The lubricated design reduces maintenance needs, making it ideal for automated systems.
