The CRBC15030UU is a crossed roller bearing with a 150mm bore and 230mm outer diameter, designed for combined loads. Its compact 30mm width and steel construction make it sturdy yet space-efficient.
This bearing handles loads up to 100kN, with a double-seal design to keep dirt out and lubrication in. It operates smoothly in temperatures from 0°C to 110°C, suitable for demanding environments.
The press-fit shaft mount ensures a secure installation, while the ABEC5 rating (upgradable to ABEC7/9) offers precision for high-accuracy applications. Ideal for robotics, machine tools, or rotary tables where stability matters.
Weighing 5.3kg, it’s robust for industrial use. Compliant with RoHS and REACH standards, it’s a reliable choice for engineers and maintenance teams.
"*" indicates required fields
How Does CRBC15030UU Bearing Handle Combined Loads?
CRBC15030UU Bearing is designed with a single-row crossed roller construction, ideal for handling combined loads efficiently.
Its steel rings and rollers provide a basic load rating of 100 kN, ensuring reliable performance in various applications.
The double-seal design protects CRBC15030UU Bearing from contaminants, extending its service life.
With a temperature range of 0-230°F, it performs well in diverse operating conditions.
CRBC15030UU Bearing’s press-fit shaft mount simplifies installation, reducing setup time.
Its ABEC5 rating ensures precision, with options for higher accuracy (ABEC7/9) if needed.
The compact 30 mm width of CRBC15030UU Bearing saves space without compromising strength.
Weighing 5.3 kg, it balances durability and ease of handling.
Industrial Uses of CRBC15030UU Bearing
CRBC15030UU Bearing is commonly used in machine tools, where its crossed roller design handles combined loads with precision. The double seal helps keep contaminants out, making it suitable for dusty workshop environments.
In robotics, CRBC15030UU Bearing provides smooth rotation for joints and swivel mechanisms. Its press-fit mounting ensures stability during high-precision movements.
For medical imaging devices, CRBC15030UU Bearing’s steel construction offers durability under frequent use. The ABEC5 rating ensures consistent performance in sensitive diagnostic equipment.
Automotive applications like steering systems benefit from CRBC15030UU Bearing’s load capacity. The metric sizing makes it compatible with various vehicle designs.
In 3D printers, CRBC15030UU Bearing supports the gantry for accurate print head movement. Its temperature range allows reliable operation during long printing sessions.
