The JB047XP0 is a slim, sealed ball bearing measuring 4.75″ in bore and 5.375″ in outer diameter, with a compact width of just 0.3125″. Made from chrome steel with a brass cage, it offers reliable performance in tight spaces.
This four-point contact bearing handles radial loads up to 1193 lbf and thrust loads up to 1900 lbf, suitable for moderate-speed applications. Its sealed design keeps lubrication in and contaminants out, reducing maintenance needs.
The bearing operates smoothly in temperatures from -30°C to 110°C and is interchangeable with KAYDON models. Ideal for robotics or precision machinery where space is limited but performance can’t be compromised.
Weighing only 0.35 lbs, it’s lightweight yet sturdy, meeting ABEC-1 tolerance standards. RoHS compliant for safe use in various industrial settings.
"*" indicates required fields
Performance Features of JB047XP0 Bearing
JB047XP0 Bearing is designed with chrome steel rings and balls, offering strong resistance to both radial and thrust loads.
Its dynamic radial load capacity reaches 1193 lbf, while the static thrust load goes up to 5080 lbf, ensuring reliable performance.
The brass cage keeps the balls aligned, reducing wear and extending service life.
With a temperature range of -30°C to 110°C, it works well in various environments.
Industrial Uses of JB047XP0 Bearing
JB047XP0 Bearing is commonly used in industrial automation, particularly in robotic arms and precision machinery where its thin section design saves space without sacrificing load capacity. The sealed construction helps keep contaminants out, extending service life in dusty environments.
Where Is JB047XP0 Bearing Used?
You’ll find JB047XP0 Bearing in medical imaging devices, where its smooth operation and precise tolerances ensure accurate positioning. The brass cage adds durability, making it reliable for high-use medical applications.
Built for Heavy-Duty Use: JB047XP0 Bearing
JB047XP0 Bearing handles heavy loads in construction equipment like crane rotators, thanks to its four-point contact design. The chrome steel rings and balls provide excellent wear resistance, even under constant stress.
Automotive vs Aerospace: Applications of JB047XP0 Bearing
In automotive steering systems, JB047XP0 Bearing offers compact support for precise control. For aerospace applications, its lightweight design and ABEC-1 tolerance make it suitable for instrumentation and control mechanisms.
Perfect Fit for Automation: JB047XP0 Bearing
JB047XP0 Bearing works well in 3D printers and CNC machines, where its thin profile and sealed design reduce maintenance needs. The lubricated setup ensures quiet operation, ideal for precision tasks.
