Single Row Deep Groove Ball Bearings 6217-Z
Single Row Deep Groove Ball Bearings 6217-Z

Single Row Deep Groove Ball Bearings 6217-Z

The 6217-Z is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 19581 lbf and operates smoothly at speeds up to 5600 RPM.

Shielded on both sides, it keeps grease in and dirt out, reducing maintenance needs. The stainless steel cage adds durability, making it a reliable choice for long-term use.

With a temperature range of -30°C to 120°C, it suits various environments. Its P6 tolerance ensures precise performance in demanding applications.

Ideal for electric motors, pumps, or industrial gearboxes, this bearing is interchangeable with SKF models. Weighing 1.83kg, it offers a solid balance of strength and manageability.

SEND INQUIRY

"*" indicates required fields

This field is for validation purposes and should be left unchanged.

Product Parameters

  • Part Number 6217-Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 28 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 19581 lbf
  • Static Radial Load 14388 lbf
  • Max Speed 5600 rpm
  • Weight 1.83 kg
  • price($) 43.92

Features

Performance Features of 6217-Z Bearing

6217-Z Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 19581 lbf, ensuring reliable performance in various applications.

The stainless steel cage maintains ball alignment, reducing friction and extending service life.
With a maximum speed of 5,600 rpm, it delivers a balance of durability and efficiency.

6217-Z Bearing operates smoothly in temperatures from -30° to 120°C, suitable for diverse environments.
Its shielded design helps keep contaminants out, reducing maintenance needs.

The grease lubrication ensures consistent performance, even under heavy loads.
Its P6 tolerance class provides precision, making it ideal for demanding tasks.

Application

Industrial Uses of 6217-Z Bearing
6217-Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures it can handle radial loads efficiently in demanding environments.

What Makes 6217-Z Bearing a Preferred Choice?
In automotive applications, 6217-Z Bearing fits well in wheel hubs and transmission systems, offering reliable performance. Its P6 tolerance class provides the precision needed for smooth operation in vehicles.

Perfect Fit for Automation: 6217-Z Bearing
For automation equipment, 6217-Z Bearing works seamlessly in conveyor belts and robotic arms. The grease lubrication reduces maintenance needs, making it a practical choice for continuous operation.

Medical vs Industrial: Where 6217-Z Bearing Excels
While 6217-Z Bearing is sturdy enough for industrial gear, its precision also suits medical devices like centrifuges. The stainless steel cage adds durability, ensuring long-term performance in both fields.
